Crown Power Solar Fence Energizer – 20 Acre Solar Jhatka Machine
Machine Power:
10 kv
Price:
₹5,800
Area:
20 acre
Warranty:
12 months
Machine Type:
Solar
The Crown Power CR5000 Solar Fence Energizer is a robust 12 V DC solar fencing controller delivering up to 10 000 V and suitable for areas up to 20 acres. With built-in low-battery cut-off, lightning protection, 10‑stage LED voltage indicator, and automatic battery-saving mode.
☆☆☆☆☆ No reviews yet. Write Review
The Crown Power Fencing CR5000 is a powerful and reliable solar fencing energizer, designed to protect farms up to 20 acres. Operating at 12 V DC, it delivers up to 10,000 V output pulses and includes advanced safety and efficiency features tailored for Indian agricultural conditions.
⚙️ Key Features
- 10,000 V output suitable for 2 km fencing or approx. 20 acres of coverage.
- 10‑stage LED Voltage Indicator to monitor fence pulse strength.
- Low‑Battery Indicator alerts when voltage drops below a safe level.
- Toggle Mode for reduced power consumption during cloudy days.
- Built-in Lightning Protection to safeguard during storms.
- Complies with IEC‑60335‑2‑76 :1999 safety standard.
- Lightweight (~4 kg), robust IP24 ABS housing.
- Includes connection diagram, line tester, connector wires, and earth clamps.
- 1-year warranty with prompt after-sales support.
📊 Technical Specifications
| Parameter | Detail |
|---|---|
| Input Power | 12 V DC (Battery/Solar) |
| Output Voltage | 10,000 V |
| Stored Energy | Approx. 4–5 Joules |
| Coverage Area | Up to 2 km or ~20 acres |
| Voltage Display | 10‑stage LED indicator |
| Safety Features | Low-battery cut-off, lightning protection |
| Power Mode | Toggle high/low consumption modes |
| Weight | Approx. 4 kg |
| Warranty | 1 Year |
| Safety Compliance | IEC‑60335‑2‑76 |
📦 What’s in the Box
- CR5000 Energizer Unit
- Connection cables and earth clamps
- Connection diagram & fence line tester
Note: Solar panel, battery, fencing wire, insulators, and earthing rods are sold separately but can be bundled via enquiry.
🔧 Compatible Accessories Needed
- Solar panel (20–40 W)
- 12 V battery (12Ah–40Ah SMF or tubular)
- High‑tensile fencing wire (GI or aluminum, 1.6–2 mm)
- Ceramic or HDPE insulators
- Earthing rods (minimum 3 rods, 3–4 ft each)
- Fence voltage tester & warning boards
🌿 Best For These Use Cases
- Crop fields (wheat, sugarcane, pulses, vegetables)
- Orchards & plantations
- Poultry and livestock pen fencing
- Boundary fencing near forests or rural edges
- Remote farms need reliable solar operation
🧰 Installation Guidelines
- Mount energizer in a dry, shaded area 3–5 ft above ground
- Place the solar panel for maximum sun exposure
- Connect the battery, observing the correct polarity to avoid faults
- Use insulators and tensioners to install fencing wire properly
- Install earthing rods spaced apart in moist soil
- Test voltage using display or tester to ensure 8–10 kV output
⚠️ Safety Recommendations
- Keep fence wires clear of vegetation to prevent shorts
- Use warning signboards at regular intervals
- Disconnect the fence during heavy storms if possible
- Perform periodic checkups for earthing integrity and voltage output
🌟 Why Choose Crown CR5000?
- Extensive farm coverage with reliable 10 kV output
- Energy-efficient operation with power-saving mode
- Safeguards against lightning and low battery damage
- Intuitive LED indicators for quick diagnostics
- Lightweight, durable and easy to install
- Certified to international safety standards
The Crown Power CR5000 Solar Fence Energizer is perfect for Indian farmers seeking dependable, safe, and solar-based crop protection. Submit the form below to receive a customised quote, delivery estimate, and solar fencing bundle support.
